Enterprise Factory Access Control Attendance Wing Gate Face
Recognition Gate
It can provide a civilized and orderly way of passage for people
entering and leaving, and effectively manage the entry and exit of
people
Widely used in stations, docks, subways, factories, buildings,
schools, residences and other occasions where intelligent
management of passages is required
Functions & Features
1) Rapid identification technique, available to identify accurately
and efficiently the magnetic card, bar code card, ID card and IC
card.
2) DC Brushless Motor, Maintenance Free
3) On-line or off –line mode(optional)
4) Real time trouble self-detect and alarm indication, ensuring
system safe operation and facilitating maintenance and operation
5) With direction indication, guiding passenger to entry and exit.
6) Self automatic locking to prevent force passing without the card
7) Automatic counting and displaying number of passenger,
facilitating observation and with a displaying total amount as high
as 90,000
8) Light and sound alarm indication function, preventing illegal
entry or irregular passing
9) Powerful on-line intelligent control mode, facilitating you:
A) To adjust the operation speed of the barrier according to the
flow of passenger and improve the passing rate.
B) To set up operation mode for passage entry and exit.
C) To read card with multiple times, the special function meeting
the application requirements of a particular site.
D) To set up the card reading with or without memory.
E) To select a reasonable normally open or close mode, to divert
the flow of passengers effectively.
F) Setting function humanized for reset of over time passing.
10) The infrared sensing technique realizes real time monitor of
passage, safe protection and tail-proof.
12) The processing mode in emergency or in special conditions.
13) Having standard input/output port, facilitating the integration
of the system and the other equipment, to realize far end control
management.
14) Super combination capability, with the combined application of
products of different passage types and series, not affecting the
system performance.
15) Strong system expending capability, available to add new
product at any time
16) Far end control management: function to far end control of
barrier mode, meeting the special requirements of the users and the
fire protection
| Infrared radio | 5 pairs |
| trouble-free operation | 2 million times |
| average life span | 3 million times |
| Channel width | 600mm |
| Door wing material | soft double wings |
| Product size | length 1200mm x width 280mm x height 990 mm |
| Channel frame | 304 stainless steel |
| Packing weight | bout 65 KG (single side lane) |
Application Of Flap Barrier Gate
- lobby entry
- Subway
- Airports
- Stations,Library
FAQ
1.Can you accept OEM or ODM ?
Yes, We provide customized services according to your detailed
requirements, also can design unique gate
according to your actual site, and produce different sizes,
software and functions.
2. How do you do after-sales service?
We provide life-long technical support online through e-mail,
video, telephone, etc., 7*24 hours a day service,
One-year warranty and lifetime technical support.
3. How about the delivery time?
It takes 7-10 working days for regular products. It takes 15-20
working days for customized products.
4.What is your payment method?
T/T 30% as deposit, 70% before delivery. Before you pay the
balance, we will show you photos or videos of the
products and packages.
